Go Pad Pro Technical Specifications
| CPU | Secure ARM Cortex M3 |
| Buttons | On/Off button, 10 numeric buttons, 5 function buttons |
| Display | 320 x 240 px touch screen display |
| Magnetic Card Reader | Triple track bi-directional |
| Smart Card Reader | Landing type |
| Contactless Reader (optional) |
NFC-A, ISO 14443 TypeA NFC-B, ISO 14443 Type B NFC-F, Felica NFC-V, ISO 15693 |
| Contactless Payments (optional) |
VISA payWave, MasterCard PayPass, American Express, DPAS (Discover), China UnionPay, J/Speedy (JCB), Common.SECC |
| Connectors | RS-232 contact pins, USB Type-C port, SAM card slot (optional), SIM card slot (optional) |
| Wired Communication | USB (device) |
| OS Compatibility | iOS, Android, Windows |
| Bluetooth (optional) | BT version 4.2 Low Energy |
| Wireless (optional) | Wi-Fi IEEE 802.11 b/g/n |
| Cellular Module (optional) | 2G/3G/4G communication |
| LED Indication | Contactless payment status |
| Audio Features | Electromagnetic buzzer |
| Power Supply | DC 5 V through USB, DC 5 V through contact pins |
| Battery | Rechargeable Li-Ion Battery, 3.7 V, 1180 mAh |
| Reliability | 500,000 chip card cycles, 1,000,000 magnetic card swipes, 1,000,000 button clicks |
| Certificates | CE, FCC, PCI PTS 6.x, EMV Level 1, EMV Level 2, EMV Level 1 Contactless, TQM |
| Dimensions | 71 x 133 x 19 mm |
| Weight | 180 g |
| Operational Temperature | -10 °C to 40 °C / 5 to 70% RH |
| Storage temperature | -15 °C to 50 °C / 5 to 70% RH |
| Drop Tested | 1.2 m, faces and edges |
| Other Box Contents | 90 cm USB Type-A to Type-C cable |
| Compatible Accessories | Charger (GT1), 5-unit charger (GT5), Metal Stand, Plastic Stand, BlueCharge-55, BluePrint-55, BlueScan-55 |
